Blocks#

A Block is a single unit of processing acting on the Image object, reading and writing its attributes. Blocks documentation include the following information:

read: the Image attributes read by the Block
write: the Image attributes written by the Block
modify data: indicates that the Image.data is modified by the Block

Detection#

`SegmentedPeaks`
`SEDetection`	Source Extractor detection.
`DAOFindStars`	DAOPHOT stars detection with `photutils` implementation.

PSF#

`Cutouts`	Extract square image cutouts centered on `Image.stars_coords`
`MedianPSF`	Get median psf from image.
`FWHM`	Fast empirical FWHM
`Gaussian2D`	Fit an elliptical 2D Gaussian model to an image effective PSF
`Moffat2D`	Fit an elliptical 2D Moffat model to an image effective PSF
`FastGaussian`	Fit a symetric 2D Gaussian model to an image effective PSF

Alignment, Centroiding#

`XYShift`	Compute the linear shift between two point clouds.
`Twirl`	Affine transform computation for images registration
`AffineTransform`	Apply an affine transformation to image and/or stars
`Cutout2D`	TODO: change name of this.

`COM`	Centroiding using `photutils.centroids.centroid_com`
`Quadratic`	Centroiding using `photutils.centroids.centroid_quadratic`
`Gaussian2D`	Centroiding using `photutils.centroids.centroid_2dg`
`BalletCentroid`	Centroiding with ballet.

Photometry#

`PhotutilsAperturePhotometry`	Aperture photometry using the `CircularAperture` and `CircularAnnulus` of photutils with a wide range of apertures.
`PhotutilsPSFPhotometry`
`SEAperturePhotometry`

Utils#

`Calibration`	Flat, Bias and Dark calibration
`Cutouts`	Extract square image cutouts centered on `Image.stars_coords`
`Flip`	Flip an image according to a reference
`ImageBuffer`	Stores the last Image
`Pass`	A Block that does nothing
`SaveReduced`	Save reduced FITS images.
`Set`	Sets specific attribute to every image
`Stack`	Build a FITS stack image of the observation
`Trim`	Image trimming.
`XArray`

All#

`AffineTransform`	Apply an affine transformation to image and/or stars
`AstroAlignShift`	Compute the linear shift between point clouds using `astroalign`
`AutoSourceDetection`
`BalletCentroid`	Centroiding with ballet.
`Calibration`	Flat, Bias and Dark calibration
`CleanBadPixels`
`CleanCosmics`
`COM`	Centroiding using `photutils.centroids.centroid_com`
`Cutout2D`	TODO: change name of this.
`Cutouts`	Extract square image cutouts centered on `Image.stars_coords`
`DAOFindStars`	DAOPHOT stars detection with `photutils` implementation.
`DataBlock`
`Del`
`Drizzle`
`FastGaussian`	Fit a symetric 2D Gaussian model to an image effective PSF
`Flip`	Flip an image according to a reference
`Function`
`FWHM`	Fast empirical FWHM
`GaiaCatalog`
`Gaussian2D`	Fit an elliptical 2D Gaussian model to an image effective PSF
`Gaussian2D`	Centroiding using `photutils.centroids.centroid_2dg`
`Get`
`HFD`
`ImageBuffer`	Stores the last Image
`KeepGoodStars`
`LimitStars`
`LivePlot`
`LocalInterpolation`
`MedianPSF`	Get median psf from image.
`MedianStack`
`Moffat2D`	Fit an elliptical 2D Moffat model to an image effective PSF
`MPCalibration`
`Pass`	A Block that does nothing
`Peaks`
`PlateSolve`
`PlotVideo`
`PointSourceDetection`
`Quadratic`	Centroiding using `photutils.centroids.centroid_quadratic`
`RawVideo`
`RemoveBackground`
`SaveReduced`	Save reduced FITS images.
`SEDetection`	Source Extractor detection.
`SegmentedPeaks`
`Set`	Sets specific attribute to every image
`Shepard`
`Stack`	Build a FITS stack image of the observation
`StackStd`
`TESSCatalog`
`TraceDetection`
`Trim`	Image trimming.
`Twirl`	Affine transform computation for images registration
`WriteTo`	Write image to FITS file
`XArray`
`XArray2`
`XYShift`	Compute the linear shift between two point clouds.
